FC-161BNC

pad printing machine by single-color ink cup / table based

FC-161BNC

pad printing machine by single-color ink cup / table based

This Tagless pad printer is economical and convenient, easy for moving by one person and delivery by small car.65536 Color TFT Touch Panel.Controlled by PLC , easier for adding other functions. The pad printing machine uses Exclusive Patented Adjustable Ink-Scrape Mechanism (Patent No. M311585).
Add RFQ RFQ results

Product Info

Printed Product


pad printing machine by single-color ink cup / table based-FC-161BNC

Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.

Features :

  • Economic, convenience, easy for moving by one person and delivery by small car

  • The pad printer is fully upgraded with a 7-inch color touch panel screen and PLC controller. Good visual effect, easy operation, easier and more convenient to use. The man-machine interface can be easily switched to select the language:English, Indonesian, Vietnamese ,Thai andTraditional Chinese.

  • Controlled by PLC , easier for adding other functions

  • Malfunction screen display

  • The pad printing machine uses Exclusive Patented Adjustable Ink-Scrape Mechanism (Patent No. M311585)

  • L shape casting structure:strong and easy to operate

  • The pad printer has a stylish appearance and lightweight

  • Fine Cause produced pad printers own exclusive patent (No. M311585) and is different from others which only use magnet for suction function. Our new double-axis ink-scarping system makes it better and cleaner for scraping the ink.



Suitable For :

special product printing, toys, stationery, watches, accessories, electronic products, switches, buttons, lighter surface and so on.

Plastic printing, metal finished products, semi-finished products, ceramics glass product or uneven surface printing.

Additional precision indexing plate makes it easy to access materials.

It is also able to expand the automation peripherals to increase production.





Specifications

Machine Type Printing color Using steel plate size Productivity/per hour Machine size Net weight
FC-161BNC 1 L:200 W:90 H:10 1200~1800 L:60 W:60 H:125 40KG



Machine specification FC-161BNCSingle-ColorInk-Cup Pad-Printer  FC-161DNC MiniSingle-ColorInk-Cup Pad-Printer  FC-161ANCSingle-ColorInk-Cup Pad-Printer  FC-161CNCHorizontal ScrapingSingle-ColorInk-Cup Pad-Printer FC-191ANCSingle-ColorInk-Cup Pad-Printer-90Ø
Air pressure(kg/cm2 psi) 4~6 4~6 4~6 4~6 4~6
Power consumption (ampere)(A) 3 3 3 3 3
Power (V) 110V & 220V 110V & 220V 110V & 220V 110V & 220V 110V & 220V
Table size(mm) 60*110 80*220 80*220 80*220 80*220

Maximum printing range(mm)

Ø55 Ø50
Ø50 170*50 Ø75
Maximum printing height(mm) 120 180 180 180 180
Left-right printed range(mm) 125 (Front/Back) 125(Front/Back) 125(Front/Back) 160 (Left to Right) 125(Front/Back)
Rubber pad to steel plate height(mm) 94 94 100 100 100
Maximum steel plate size(mm) 90*200 90*200 90*200 80*350 120*240
