FC-101ANC

Ink-Tray Pad Printing Machine by One-Color

FC-101ANC

Ink-Tray Pad Printing Machine by One-Color

Classic style which is one of the common types in the worldwide. Exclusive devices with front and back sliding sleeve system. It greatly enhances the precision of the pad printing machine running.
Add RFQ RFQ results

Product Info

Ink-Tray Pad Printing Machine by One-Color-FC-101ANC

Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.

 Feature :

  • Finecause traditional and common type – FC-101ANC, 1 stand for moving of rubber (125mm).  In addition, 1 also stand for what size of the machine.  Moreover, 2 stand for moving of rubber(200mm).  Finally, 3 stand for moving of rubber(300mm).

    • FC-101ANC- 0 stand for the round plate pad printer

    • FC-191ANC – 1 stand for single color machine

  • The same pad printing machine can go with 90mm of ink cup or double groups of ink cups even more like 3 groups of ink cups becomes 2-color machine or 3-color machine.

  • Client can choose paid add additional installation peripheral devices like slide rail, round plate, oval plate, suction function, flip function, rotary function, and blow dryer shelf and so on.

  • Built in smart bar chart, production data displayed by graphs in the past 30 days. Connect with FineCause smart factory APP, no matter where you are, you can overview the production data of your pad printer.
  • It can also go with Finecause slim module

  • Built-in intelligent software which show column chart of past 30 days on the screen

  • 7.0" HMI touch panel with 65536 color TFT, built-in Chinese, English, Bahasa language, Vietnamese and Thai.

    • Input & output full display

    • Abnormal warning display, convenient for quickly eliminate abnormalities

    • Digital pressure sensor, automatic alarm display for insufficient air pressure

    • Able to set the number of times which Pad-Print Printing is used, and it will automatically stop and display inform when the number is arrives.

  • PLC Programmable Logic Controller easy to add and modify function

  • Emdedded Cost Saving Light Bulb
  • Malfunction Detector. Screen Display
  • Electronic Air Pressure Sensor



Suitable for :

Toys, Stationery, Jewelry, Watch Surface, Eelectronic Products, Switches, Buttons, Metalfinished and semi-finished products, Ceramic Glass products, uneven surface printing.
Additional precision indexing plate makes it easy to access the materials. It is also able to expand the automation peripherals to increase production.


Specifications

Model FC-101ANC
Color 1
Cycles/hr  1200~1800 Pcs
Machine Size (cm)  L:63 W:40 H:120
Weight 105 Kgs
Pressure
(kg/cm2 psi)
4~6
Power (A)
Ampere
5
Voltage (V) 110V or 220V
Max. Printing Area
(mm)
80*80、100*100
Max. Height of
Printed Object
(mm)
180mm
Height -
Pad Stand to Steel Plate
(mm)
100
Max.
Steel Plate Size
(mm)
L:80 W:80 H:10
L:100 W:100 H:10
