3-Color Pad Printer w/12 Station Conveyor

FC-263AOC-MR

FC-263AOC-MR

3-Color Pad Printer w/12 Station Conveyor

The pad printing machine uses Japan DAIDO Oiless Bearing system, 60mm sealed ink cup, Conveyor operate by servo motor driver. The pad printing machine uses Exclusive Patented Adjustable Ink-Scrape Mechanism (Patent No. M311585).heated-air dryer – to decrease ink drying cycle time.

Add RFQ RFQ results

Product Info

3-Color Ink Cup Pad Printer w/12 Station Conveyor-FC-263AOC-MR

Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.

■ Features：

The pad printer is fully upgraded with a 7-inch color touch panel screen and PLC controller. Good visual effect, easy operation, easier and more convenient to use. The man-machine interface can be easily switched to select the language:Traditional Chinese, English, Indonesian, Vietnamese and Thai.
Easy to add additional devices.
- Ex. slide rail, round plate, oval plate, suction function, flip function, rotate function, and blow dryer shelf, etc.
Sheet metal + Powder coating machine structure. (Patent No. M456283)
The pad printing machine uses Japan DAIDO Oiless Bearing system
60mm sealed ink cup
Conveyor operate by servo motor driver
Exclusive Patented Adjustable Ink-Scrape Mechanism (Patent No. M311585)
heated-air dryer – to decrease ink drying cycle time

■ Suitable for：coins printing, toys, stationery, watches, accessories, electronic products, switches, buttons, lighter surface and so on.

Plastic printing, metal finished products, semi-finished products, glass ceramics product or uneven surface printing.

Additional precision indexing plate makes it easy to access materials.It is also able to expand the automation peripherals to increase production.

Specifications

Machine Type	FC-263AOC-MR
Color	3
Plate size(mm)	L:140 W:70 H:10
Cycles/hr	900~1200 Pcs
Machine Size (cm)	L:93 W:130 H:71
Weight	150KG
Pressure (kg/cm2 psi)	4~6(kg/cm2 psi)
Power (A) Ampere	10A
Voltage (V)	220V
Max. Printing Area (mm)	Ø50
Height - Pad Stand to Steel Plate (mm)	94
Max. Steel Plate Size (mm)	L:140 W:70 H:10
