FC-301ANC

Large-Sized Single-Color Ink Tray Pad Printer

FC-301ANC

Large-Sized Single-Color Ink Tray Pad Printer

It's the biggest size of the standard machine. The height of rubber able to installed achieve 270mm, suitable for large size of printing or covering printing.Exclusive Patented Adjustable Ink-Scrape Mechanism (Patent No. M311585). Sheet Metal + Powder Coating Machine Body. Fashion Appearance (Patent No. M456283)
Add RFQ RFQ results

Product Info



Large-Sized Single-Color Ink Tray Pad Printer-FC-301ANC

It's the biggest size of the standard machine.  The height of rubber able to installed achieve 270mm, suitable for large size of printing or covering printing.

Fine Cause's pad printing machine imported to industrial I.O.T., combine smart factory App, assist you to implement production management goals through synchronous monitoring.

Feature :

  • Client can choose paid add additional installation peripheral devices like round plate, oval plate, suction function, pressing material, pusher positioning, auto pusher mechanism, industrial camera, blow dryer shelf and so on.

  • Built-in intelligent software which show column chart of past 30 days on the screen

  • Steel plate size : 260x240 mm

  • Ink-Plate size : 10 inch

  • Rubber pads max size : φ260mm

  • 10.1" HMI touch panel with 65536 color TFT, built-in Chinese, English, Bahasa language, Vietnamese and Thai.

    • Input & output full display

    • Abnormal warning display, convenient for quickly eliminate abnormalities

    • Digital pressure sensor, automatic alarm display for insufficient air pressure

    • Able to set the number of times which Pad-Print Printing is used, and it will automatically stop and display inform when the number is arrives.

  • PLC Programmable Logic Controller easy to add and modify function

  • Malfunction Detector. Screen Display
  • Embedded Cost Saving Light Bulb

  • Exclusive Patented Adjustable Ink-Scrape Mechanism (Patent No. M311585)

  • Sheet Metal + Powder Coating Machine Body. Fashion Appearance (Patent No. M456283)


■ Application :
Suitable for Large Size Printing such as helmets, large balls, buckets and etc.

Specifications

Model FC-301ANC
Color 1
Platform Size (mm) 190*320
Cycles/hr  6-15  Pcs
(Depending on size of the printing deign or printing conditions)
Machine Size (cm)  L:160 W:65 H:175
Weight 450 KG
Pressure
(kg/cm2 psi)
4~6
Ink Tray Size: 10 Inches
Power (A)
Ampere
5A
Voltage (V) 110V or 220V
Max. Printing Area
(mm)
200*200
Max. Height of
Printed Object
(mm)
200
Height -
Pad Stand to Steel Plate
(mm)
300
Max.
Steel Plate Size
(mm)
L:260 W:240 H:10
